Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
RQ3E075ATTB
Manufacturer
ROHMManufacturer Product Number
RQ3E075ATTB
Description
栅极电压Vgs：±20V Pd-功率耗散(Max)：15W(Tc) Rds On(Max)@Id,Vgs：23mΩ@7.5A,10V 工作温度：-55°C~150°C(TJ) 封装/外壳：HSMT
Manufacturer Standard Lead Time
5-7个
Detailed Description
Product Attributes
| Type | Description |
|---|---|
| Category | Boxes, Enclosures, Racks andBox Components |
| Operating Temperature | -55℃~150℃ |
| Drain-Source Voltage | 30V |
| Continuous Drain Current | 7.5 A |
| Type | P-Channel |
| Power | 15W |
| Threshold Voltage | 2.5V@1mA |
| Gate Charge | 10.4nC@4.5V |
| On-Resistance | 23mΩ@7.5A, 10V |
| Input Capacitance | 930pF@15V |
Documents & Media
| Resource Type | Link |
|---|
Environmental & Export Classifications
| Attribute | Description |
|---|
Additional Resources
| Attribute | Description |
|---|
In Stock: 273
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1+ | $ 0.5598 | |
| 10+ | $ 0.5459 | |
| 30+ | $ 0.5347 | |
| 100+ | $ 0.5264 |
Price For：Each
Minimum:1/Multiple:1
Total amount:
