Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
1206L175SLYR
Manufacturer
LittelfuseManufacturer Product Number
1206L175SLYR
Description
PTC RESET 6V LO RHO 1206 1.75A
Manufacturer Standard Lead Time
10-15
Detailed Description
Product Attributes
| Type | Description |
|---|---|
| Category | Boxes, Enclosures, Racks andBox Components |
| Operating Temperature | -40℃~85℃ |
| Maximum Voltage | 6V |
| Maximum Current | 50A |
| Trip Current | 3.5A |
| Resistance After Trip | 30mΩ |
| Initial Resistance Value | 5mΩ |
| Maximum Operation Time | 400ms |
| Holding Current | 1.75A |
Documents & Media
| Resource Type | Link |
|---|
Environmental & Export Classifications
| Attribute | Description |
|---|
Additional Resources
| Attribute | Description |
|---|
In Stock: 10
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1+ | $ 2.1612 | |
| 5+ | $ 1.7950 | |
| 10+ | $ 1.6557 | |
| 50+ | $ 1.3730 | |
| 100+ | $ 1.2672 | |
| 250+ | $ 1.1391 | |
| 500+ | $ 1.0500 | |
| 1000+ | $ 0.9790 |
Price For：Each
Minimum:1/Multiple:1
Total amount:
