Image shown is a representation only. Exact specifications should be obtained from the product data sheet.
0805L110WR
Manufacturer
LittelfuseManufacturer Product Number
0805L110WR
Description
1.1A 0805 SMD resettable PTCs
Manufacturer Standard Lead Time
10-15
Detailed Description
Product Attributes
| Type | Description |
|---|---|
| Category | Boxes, Enclosures, Racks andBox Components |
| Holding Current | 1.1A |
| Maximum Current | 100A |
| Operating Temperature | -40℃~85℃ |
| Maximum Voltage | 6V |
| Maximum Operation Time | 100ms |
| Trip Current | 2 A |
| Initial Resistance Value | 50mΩ |
| Resistance After Trip | 160mΩ |
Documents & Media
| Resource Type | Link |
|---|
Environmental & Export Classifications
| Attribute | Description |
|---|
Additional Resources
| Attribute | Description |
|---|
In Stock: 2,118
| Quantity | Unit Price | Ext Price |
|---|---|---|
| 1+ | $ 1.3536 | |
| 5+ | $ 1.2909 | |
| 3000+ | $ 1.2909 |
Price For：Each
Minimum:1/Multiple:1
Total amount:
Associated Product
See All0805L110WR-A
自恢復保險絲 - PPTC PTC 6V POLYFUSE SURF MOUNT 0805 1.1A
Littelfuse
0805L125/6NR
--
LUTE
0805L125SL6ARG
品牌:LUTE（陆特）, 封装:0805, 最大电流:50A, 最大电压:6V, 保持电流:1.25A, 跳闸电流:2.5A, 初始态阻值:30mΩ, 工作温度:-40℃~85℃, 最大动作时间:1S, 跳断后阻值:160mΩ, 消耗功率:1.2W
LUTE
0805L150/12SLYR
自恢復保險絲 - PPTC
Littelfuse
